48V / 5kW DC SepEx Motor

19 teeth spline, speed sensor, Class F insulation

We supply also the speed sensor of motor XQ-5-19MT.

Speed Sensor Connector

XQ-5-19MT is used as traction motor of golf carts. Typical application: EPIC Cart 6-seat golf cart.

Specifications:

• Nominal power rate: 5.0 kW
• Operating voltage: 48V
• Current: 120A
• Exciting current: 7A
• Duty: 60min
• Speed: 4000 rpm
• Ingress Protection: IP 44
• Speed sensor mating connector is included
• Insulation: Class F
• Weight: 37.9 kg (package weight: 40 kg)
